Strung automat CNC

OKUMA L300-MW

Stare: folosit, An de fabricație: 2015, Funcționalitate: funcționalitate restrânsă, număr mașină/vehicul: MW130, Technical characteristics: Work Area # Maximum turning diameter: 300 mm # Maximum workpiece length: 276 mm # X - axis travel distance: 250 mm / Rapid speed in X: 24 m/min # Z - axis travel distance: 460 mm / Rapid speed in Z: 24 m/min Ffsdpfxexxrbbj Adgjw # W -axis travel distance: 520 mm / Rapid speed in Z: 24 m/min Main Spindle # Spindle size : A2-8 # Maximum speed: Left 3000 rpm # Power with 100% ED : Left -15 kW / Right 7.5 kW # Max diameter on bench: 520 mm # C axis indexing precision : 0.001 [°] # Bar Capacity: left spindle - 80 mm / right spindle - 53 mm Counter- Spindle: # Spindle speeds : 6000 [rpm] # Max. bar diameter : 53 [mm] # C axis indexing precision : 0.001 [°] # Travel : 520 [mm] Tool Holder with Motorized Tools # Tool Interface: Okuma interface # Number of position : 12 lower -station disc turret, all driven positions # Maximum speed: 4500 rpm, Milling motor power : 4.5 kW Electrical Equipment # Operating voltage: 400Vx3, fusible 151A # Connection power: 22.5 kVA Dimensions # Machine Dimensions (L×W×H): 3200 ×2200× 1900 mm ;Weight : 5500 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation, Parts catcher + Custom made Parts conveying strip # CNC Control: OSP-P300L-R # Chip extraction conveyor # FIRE PROTECTION SYSTEM # TOOL MEASURING SYSTEM (Q SETTER) # Broken tool detection system : Load force auto learning analizer controlled by OSP-P300L-R # Part detection Counter spindle : Low pressure compressed air gauges. # SPINDLE COOLING SYSTEM, # Documentation : Electronic available / Book available Machine status : WORKING only with main spindle - sub spindle needs repaired OPTIONAL # Barr feeder : TopAutomazione model FU352 # Bar feeder (L×W×H): 3500 ×800× 1200 mm ;Weight : 1500 Kg

Stare: folosit, An de fabricație: 2017, Funcționalitate: funcționalitate restrânsă, număr mașină/vehicul: MW149, Technical characteristics: Work Area # Maximum turning diameter: 300 mm # Maximum workpiece length: 276 mm # X - axis travel distance: 250 mm / Rapid speed in X: 24 m/min # Z - axis travel distance: 460 mm / Rapid speed in Z: 24 m/min # W -axis travel distance: 520 mm / Rapid speed in Z: 24 m/min Main Spindle Fodexxiiijpfx Adgsfw # Spindle size : A2-8 # Maximum speed: Left 3000 rpm # Power with 100% ED : Left -15 kW / Right 7.5 kW # Max diameter on bench: 520 mm # C axis indexing precision : 0.001 [°] # Bar Capacity: left spindle - 80 mm / right spindle - 53 mm Counter- Spindle: # Spindle speeds : 6000 [rpm] # Max. bar diameter : 53 [mm] # C axis indexing precision : 0.001 [°] # Travel : 520 [mm] Tool Holder with Motorized Tools # Tool Interface: Okuma interface # Number of position : 12 lower -station disc turret, all driven positions # Maximum speed: 4500 rpm, Milling motor power : 4.5 kW Electrical Equipment # Operating voltage: 400Vx3, fusible 151A # Connection power: 22.5 kVA Dimensions # Machine Dimensions (L×W×H): 3200 ×2200× 1900 mm ;Weight : 5500 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation, Parts catcher + Custom made Parts conveying strip # ADDITIONAL EMULSION TANK WITH 10 BAR PRESSURE FOR CUTTING TOOL COOLING # CNC Control: OSP-P300L-R # Chip extraction conveyor # FIRE PROTECTION SYSTEM # TOOL MEASURING SYSTEM (Q SETTER) # Broken tool detection system : Load force auto learning analyzer controlled by OSP-P300L-R # Part detection Counter spindle : Low pressure compressed air gauges. # SPINDLE COOLING SYSTEM, # Documentation : Electronic available / Book available OPTIONAL: Barr feeder : TopAutomazione FU352SX # Bar feeder (L×W×H): 3500 ×800× 1200 mm ;Weight : 1500 Kg Machine status : WORKING only with main spindle - sub spindle needs repaired

Stare: necesită reparații (utilizat), An de fabricație: 2016, Funcționalitate: nefuncțional, număr mașină/vehicul: MW144, Technical characteristics: Work Area # Maximum turning diameter: 300 mm # Maximum workpiece length: 276 mm # X - axis travel distance: 250 mm / Rapid speed in X: 24 m/min # Z - axis travel distance: 460 mm / Rapid speed in Z: 24 m/min # W -axis travel distance: 520 mm / Rapid speed in Z: 24 m/min Main Spindle # Spindle size : A2-8 # Maximum speed: Left 3000 rpm # Power with 100% ED : Left -15 kW / Right 7.5 kW # Max diameter on bench: 520 mm # C axis indexing precision : 0.001 [°] # Bar Capacity: left spindle - 80 mm / right spindle - 53 mm Counter- Spindle: # Spindle speeds : 6000 [rpm] # Max. bar diameter : 53 [mm] # C axis indexing precision : 0.001 [°] # Travel : 520 [mm] Tool Holder with Motorized Tools # Tool Interface: Okuma interface # Number of position : 12 lower -station disc turret, all driven positions # Maximum speed: 4500 rpm, Milling motor power : 4.5 kW Electrical Equipment # Operating voltage: 400Vx3, # Connection power: 22.5 kVA Dimensions # Machine Dimensions (L×W×H): 3200 ×2200× 1900 mm ;Weight : 5500 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation, Parts catcher + Custom made Parts conveying strip # CNC Control: OSP-P300L-R # Chip extraction conveyor # FIRE PROTECTION SYSTEM # TOOL MEASURING SYSTEM (Q SETTER) # Broken tool detection system : Load force auto learning analyzer controlled by OSP-P300L-R # Part detection Counter spindle : Low pressure compressed air gauges. # SPINDLE COOLING SYSTEM, # Documentation : Electronic available / Book available OPTIONAL Barr feeder : TOP Automazzione model : FU 352 # Bar feeder (L×W×H): 3500 ×800× 1200 mm ;Weight : 1500 Kg Machine status : NOT WORKING # Turret -disassembled to be repaired # Ball screw X axis - to be replaced # Heat exchanger oiling unit - to be replaced # Hydraulic unit - to be replaced # Sub spindle - to be repaired # Position encoder Spindle - to be replaced # Chip conveyor - to be repaired # Kit of guides and accessories for bars clamping # Kit of bearings for pusher head Ffedexxidajpfx Adgow

Stare: necesită reparații (utilizat), An de fabricație: 2015, Funcționalitate: nefuncțional, număr mașină/vehicul: MW137, Technical characteristics: Work Area # Maximum turning diameter: 300 mm # Maximum workpiece length: 276 mm # X - axis travel distance: 250 mm / Rapid speed in X: 24 m/min # Z - axis travel distance: 460 mm / Rapid speed in Z: 24 m/min # W -axis travel distance: 520 mm / Rapid speed in Z: 24 m/min Main Spindle # Spindle size : A2-8 # Maximum speed: Left 3000 rpm # Power with 100% ED : Left -15 kW / Right 7.5 kW # Max diameter on bench: 520 mm # C axis indexing precision : 0.001 [°] # Bar Capacity: left spindle - 80 mm / right spindle - 53 mm Counter- Spindle: # Spindle speeds : 6000 [rpm] # Max. bar diameter : 53 [mm] # C axis indexing precision : 0.001 [°] # Travel : 520 [mm] Tool Holder with Motorized Tools # Tool Interface: Okuma interface # Number of position : 12 lower -station disc turret, all driven positions # Maximum speed: 4500 rpm, Milling motor power : 4.5 kW Electrical Equipment # Operating voltage: 400Vx3, fusible 151A # Connection power: 22.5 kVA Dimensions Fodpfx Adjxxh Udjgjfw # Machine Dimensions (L×W×H): 3200 ×2200× 1900 mm ;Weight : 5500 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation, Parts catcher + Custom made Parts conveying strip # ADDITIONAL EMULSION TANK WITH 10BAR PRESSURE FOR CUTTING TOOL COOLING # CNC Control: OSP-P300L-R # Chip extraction conveyor # FIRE PROTECTION SYSTEM # TOOL MEASURING SYSTEM (Q SETTER) # Broken tool detection system : Load force auto learning analyzer controlled by OSP-P300L-R # Part detection Counter spindle : Low pressure compressed air gauges. # SPINDLE COOLING SYSTEM, # Documentation : Electronic available / Book available OPTIONAL - # Barr feeder : FMB model : Turbo 10-72XT/3200/A # Bar feeder dimensions (L×W×H): 3500 ×800× 1200 mm; Weight: 1500 Kg Machine status : NOT WORKING # Encoder X axis - broken

Stare: folosit, An de fabricație: 2016, Funcționalitate: funcționalitate restrânsă, număr mașină/vehicul: MW127, Technical characteristics: Work Area # Maximum turning diameter: 300 mm # Maximum workpiece length: 276 mm # X - axis travel distance: 250 mm / Rapid speed in X: 24 m/min # Z - axis travel distance: 460 mm / Rapid speed in Z: 24 m/min # W -axis travel distance: 520 mm / Rapid speed in Z: 24 m/min Main Spindle # Spindle size : A2-8 # Maximum speed: Left 3000 rpm # Power with 100% ED : Left -15 kW / Right 7.5 kW # Max diameter on bench: 520 mm # C axis indexing precision : 0.001 [°] # Bar Capacity: left spindle - 80 mm / right spindle - 53 mm Counter- Spindle: # Spindle speeds : 6000 [rpm] # Max. bar diameter : 53 [mm] # C axis indexing precision : 0.001 [°] # Travel : 520 [mm] Tool Holder with Motorized Tools # Tool Interface: Okuma interface # Number of position : 12 lower -station disc turret, all driven positions # Maximum speed: 4500 rpm, Milling motor power : 4.5 kW Electrical Equipment # Operating voltage: 400Vx3, fusible 151A Fodpfx Aoxxihfsdgjfw # Connection power: 22.5 kVA Dimensions # Machine Dimensions (L×W×H): 3200 ×2200× 1900 mm ;Weight : 5500 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation, Parts catcher + Custom made Parts conveying strip # ADDITIONAL EMULSION TANK WITH 10 BAR PRESSURE FOR CUTTING TOOL COOLING # CNC Control: OSP-P300L-R # Chip extraction conveyor # FIRE PROTECTION SYSTEM # TOOL MEASURING SYSTEM (Q SETTER) # Broken tool detection system : Load force auto learning analyzer controlled by OSP-P300L-R # Part detection Counter spindle : Low pressure compressed air gauges. # SPINDLE COOLING SYSTEM, # Documentation : Electronic available / Book available Machine status : WORKING only with main spindle - sub spindle needs to be repaired OPTIONAL: Barr feeder : TopAutomazione model Fu352 SX # Bar feeder (L×W×H): 3500 ×800× 1200 mm ;Weight : 1500 Kg

Stare: folosit, An de fabricație: 2016, Funcționalitate: complet funcțional, număr mașină/vehicul: MW141, Technical characteristics: Work Area # Maximum turning diameter: 300 mm # Maximum workpiece length: 276 mm # X - axis travel distance: 250 mm / Rapid speed in X: 24 m/min # Z - axis travel distance: 460 mm / Rapid speed in Z: 24 m/min # W -axis travel distance: 520 mm / Rapid speed in Z: 24 m/min Fodpfxexxifkj Adgjfw Main Spindle # Spindle size : A2-8 # Maximum speed: Left 3000 rpm # Power with 100% ED : Left -15 kW / Right 7.5 kW # Max diameter on bench: 520 mm # C axis indexing precision : 0.001 [°] # Bar Capacity: left spindle - 80 mm / right spindle - 53 mm Counter- Spindle: # Spindle speeds : 6000 [rpm] # Max. bar diameter : 53 [mm] # C axis indexing precision : 0.001 [°] # Travel : 520 [mm] Tool Holder with Motorized Tools # Tool Interface: Okuma interface # Number of position : 12 lower -station disc turret, all driven positions # Maximum speed: 4500 rpm, Milling motor power : 4.5 kW Electrical Equipment # Operating voltage: 400Vx3, # Connection power: 22.5 kVA Dimensions # Machine Dimensions (L×W×H): 3200 ×2200× 1900 mm ;Weight : 5500 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation, Parts catcher + Custom made Parts conveying strip # ADDITIONAL EMULSION TANK WITH 10 BAR PRESSURE FOR CUTTING TOOL COOLING # CNC Control: OSP-P300L-R # Chip extraction conveyor # FIRE PROTECTION SYSTEM # TOOL MEASURING SYSTEM (Q SETTER) # Broken tool detection system : Load force auto learning analyzer controlled by OSP-P300L-R # Part detection Counter spindle : Low pressure compressed air gauges. # SPINDLE COOLING SYSTEM, # Documentation : Electronic available / Book available OPTIONAL: Barr feeder : FMB model : Turbo 10-72XT/3200/A # Bar feeder (L×W×H): 3500 ×800× 1200 mm ;Weight : 1500 Kg Machine status : WORKING

Stare: folosit, An de fabricație: 2017, ore de funcționare: 34.000 h, Funcționalitate: complet funcțional, număr mașină/vehicul: W6212-T63-280, Avem de vânzare un strung CNC marca Okuma-Genos, pregătit pentru lucru. Mașina este complet funcțională și a beneficiat de întreținere și service regulate. - Arbore principal și arbore de preluare Fsdpfxjw Np S Hs Adgofw - Sondă de măsurare pentru scule - Dispozitiv de evacuare a pieselor Turație arbore: 3.800 rpm Stare tehnică: Bună, mașina este la noi din nouă, achiziționată în 2017 și pusă în funcțiune în primul trimestru al anului 2018. Strungul este conectat la alimentare și funcționează. Este posibilă testarea ei în regim de lucru la sediul nostru. Decizia de vânzare este determinată de schimbările din proiectele noastre. Se poate achiziționa suplimentar un alimentator LNS pentru 10.000€ și un separator de ceață de ulei pentru 1.500€ (vizibile în poze).
