Stare: folosit, An de fabricație: 1998, Centru orizontal CNC REALMECA C300H Cursă X: 320 mm Cursă Y: 350 mm Cursă Z: 250 mm Comandă numerică: NUM 1060 Série II Con: BT 40 Turație arbore principal: de la 100 la 6000 rpm An fabricație: 10/98 Distanță maximă dintre fața arborelui și masă: max. 450 mm / min. 50 mm Magazie scule: 20 scule Filetare rapidă: max. 10 m/min Avans lucru: 0 la 10 m/min Axă B: 10 rpm Echipat cu: 2 paleți 300 x 300 mm Tensiune: 380 V Dimensiuni (L x l x h): 2450 x 1700 x 2400 mm Hjdpfxszg Ic Ds Ah Hjp Greutate: 3,8 t

Stare: folosit, An de fabricație: 2023, ore de funcționare: 2.594 h, Funcționalitate: neverificat, număr mașină/vehicul: 6000030, înălțime totală: 3.400 mm, lungime totală: 8.000 mm, lățime totală: 6.000 mm, greutate totală: 27.523 kg, număr de axe principale: 1, Dotări: transportor de șpan, Dimensiuni: 8000 x 6000 x 3400 mm Greutate: 27.500 kg Hedpfx Aszbt D Dsh Hop Ore de funcționare: 2594 h Instalație de extracție aerosoli KNOLL AerosolMaster 4000 ATS S/N 1580192 An fabricație: 2022 Transportor de șpan KNOLL 750 K-1 S/N 1591356 An fabricație: 2023

Stare: folosit, An de fabricație: 2016, Funcționalitate: complet funcțional, număr mașină/vehicul: 2460067, Technical characteristics: # Machining Workspace: X 300 mm; Y 500(725) mm; Z 375 mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1 axel of rotation table A index divider head with direct measuring system angular with no of rev. 50minˉ¹ , precision +/- 5" # Max. dimension clamping / part : Ø 575 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 65/75/75 m/min , Position precision Tp : 0.008 mm # Distance between spindles: 300 mm # Spindle speed 1-17500 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 2x32 tools / chip to chip medium 2.5 sec # Tool max.Ø75 mm / long. Max.275 mm / 7.5 kg Electrical connection: Hodpsxxtdwjfx Ah Hop # tension: 3x400V/50Hz # Power installed: aprox 85 kVA / 125A Dimensions # installation space : aprox. 3.6 x 6 x 3.7 m # weight : aprox 10500 kg Equipment consist of: # CNC control : Siemens 840D SL # Liniar axis measuring device : Heindenhain liniar scales # CHIPS EXTRACTOR Knoll Type 550 K-1 # OIL COOLING SYSTEM # OIL filtering system max 80 Bar : Knoll VRF 450_2350 # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL VAPOR ABSORPTION/RECOVERY SYSTEM : IFS Vario E2000 (2000m3/H) # Antifire : Kraft& Bauer # Part presence P/Y : with low pressure air detectors # Control in process: Marposs T25 # Control tool breakage sistem BRK and length checker: inductive sensor # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT(spindle) Machine status : WORKING

Stare: necesită reparații (utilizat), An de fabricație: 2015, Funcționalitate: nefuncțional, număr mașină/vehicul: 2460039, Technical characteristics: # Machining Workspace: X 300 mm; Y 500(725) mm; Z 375mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1 axel of rotation table A index divider head with direct measuring system angular with no of rev. 50minˉ¹ , precision +/- 5" # Max. dimension clamping / part : Ø 575 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 65/75/75 m/min , Position precision Tp : 0.008 mm # Distance between spindles: 300 mm # Spindle speed 1-17500 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 2x32 tools / chip to chip medium 2.5 sec # Tool max. Ø75 mm / long. Max.275 mm / 7.5 kg Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 85 kVA / 125A Dimensions # installation space : aprox. 3.6 x 6 x 3.7 m # weight : aprox 10500 kg Equipment consist of: # CNC control : Siemens 840D SL # Liniar axis measuring device : Heindenhain liniar scales # CHIPS EXTRACTOR Knoll Type 550 K-1 # OIL COOLING SYSTEM # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL filtering system max 80 Bar : Knoll VRF450-2450 (!!! Can serve 2 machines at once) # OIL VAPOR ABSORPTION/RECOVERY SYSTEM : IFS Vario E2000 (2000m3/H) # Antifire : Kraft& Bauer # Part presence P/Y : with low pressure air detectors Hsdpfoxxrnbsx Ah Hjp # Control in process: Marposs T25 # Control tool breakage system BRK and length checker: inductive sensor # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT(spindle) Machine status : NOT WORKING # Sensors for spindle tool presence & part presence # Tool breack sensors # Tool magasine piston and slide sistem door open/close 2 units # Tool magasine pistons and slide sistem tool holding sistem - 2 units # Position Encoder A axis # Inductive and magnetic sensors 4 units each # Chip extraction conveyor to be repaired # Chiller for cooling spindle/heat exchanger # Communication module Murr # Liniar scale X axis # Level sensor emulsion chip conveyor # Hydraulic pump # Motor for hydraulic pump (can be repaired) # Heat exchanger unit # Electric Siemens Contactors for electrical cabinet 3 units # Safety door lock Euchner # Emulsion filtration unit is shared with another machine (SW BA321 2460038)

Stare: necesită reparații (utilizat), An de fabricație: 2015, Funcționalitate: nefuncțional, număr mașină/vehicul: 2460038, Technical characteristics: # Machining Workspace: X 300 mm; Y 500(725) mm; Z 375 mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1 axel of rotation table A index divider head with direct measuring system angular with no of rev. 50minˉ¹ , precision +/- 5" # Max. dimension clamping / part : Ø 575 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 65/75/75 m/min , Position precision Tp : 0.008 mm # Distance between spindles: 300 mm # Spindle speed 1-17500 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 2x32 tools / chip to chip medium 2.5 sec # Tool max. Ø75 mm / long. Max.275 mm / 7.5 kg Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 85 kVA / 125A Dimensions # installation space : aprox. 3.6 x 6 x 3.7 m # weight : aprox 10500 kg Equipment consist of: # CNC control : Siemens 840D SL Hjdpfx Asxxrc Seh Hep # Liniar axis measuring device : Heindenhain liniar scales # CHIPS EXTRACTOR Knoll Type 550 K-1 # OIL COOLING SYSTEM # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL VAPOR ABSORPTION/RECOVERY SYSTEM : IFS Vario E2000 (2000m3/H) # Antifire : Kraft& Bauer # Part presence P/Y : with low pressure air detectors # Control in process: Marposs T25 # Control tool breakage system BRK and length checker: inductive sensor # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT (spindle) Machine status : NOT WORKING # Sensors for spindle tool presence & part presence # Hydraulic pump # Level & temperature sensor Parker for hydraulic unit # Tool magasine piston and slide system door open/close 2 units # Communication module Murr # Position encoder A Axis # Hydraulic switch Parker 4 units # Emulsion filtration unit is shared with another machine (SW BA321 2460038) # High pressure pump from emulsion filtration system

Stare: folosit, An de fabricație: 2016, Funcționalitate: complet funcțional, număr mașină/vehicul: 2460065, Technical characteristics: # Machining Workspace: X 300 mm; Y 500(725) mm; Z 375 mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1 axel of rotation table A and 2 axis of rotation B with index divider head with direct measuring system angular with no of rev. 50minˉ¹ , precision +/- 5" # Max. dimension clamping / part : Ø 575 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 65/75/75 m/min , Position precision Tp : 0.008 mm # Distance between spindles: 300 mm # Spindle speed 1-17500 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 2x32 tools / chip to chip medium 2.5 sec # Tool max. Ø75 mm / long. Max.275 mm / 7.5 kg Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 85 kVA / 125A Dimensions # installation space : aprox. 3.6 x 6 x 3.7 m # weight : aprox 10500 kg Equipment consist of: # CNC control : Siemens 840D SL # Liniar axis measuring device : Heindenhain liniar scales # CHIPS EXTRACTOR Knoll Type 550 K-1 # OIL COOLING SYSTEM # OIL filtering system max 80 Bar : Knoll 550 K-1 450_2450 (!!! Can serve 2 machines at once) # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL VAPOR ABSORPTION/RECOVERY SYSTEM : IFS Vario E2000 (2000m3/H) # Antifire : Kraft& Bauer # Part presence P/Y : with low pressure air detectors # Control in process: Marposs T25 Hjdexw Ttispfx Ah Hsp # Control tool breakage system BRK and length checker: inductive sensor # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT(spindle) # Documentation: Only books available Machine status : WORKING

Stare: folosit, An de fabricație: 2016, Funcționalitate: complet funcțional, număr mașină/vehicul: 2460062, Technical characteristics: # Machining Workspace: X 300 mm; Y 500(725) mm; Z 375 mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1 axel of rotation table A index divider head with direct measuring system angular with no of rev. 50 minˉ¹ , precision +/- 5" # Max. dimension clamping / part : Ø 575 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 65/75/75 m/min , Position precision Tp : 0.008 mm # Distance between spindles: 300 mm # Spindle speed 1-17500 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 2x32 tools / chip to chip medium 2.5 sec # Tool max. Ø75 mm / long. Max.275 mm / 7.5 kg Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 85 kVA / 125A Dimensions # installation space : aprox. 3.6 x 6 x 3.7 m # weight : aprox 10500 kg Equipment consist of: # CNC control : Siemens 840D SL # Liniar axis measuring device : Heindenhain liniar scales # CHIPS EXTRACTOR Knoll Type 550 K-1 # OIL COOLING SYSTEM # OIL filtering system max 80 Bar : Knoll VRF 450_2350 # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL VAPOR ABSORPTION/RECOVERY SYSTEM : IFS Vario E2000 (2000m3/H) # Antifire : Kraft& Bauer # Part presence P/Y : with low pressure air detectors # Control in process: Marposs T25 Hjdpsxw Syujfx Ah Hep # Control tool breakage system BRK and length checker: inductive sensor # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT(spindle) Machine status : WORKING

Stare: bun (utilizat), An de fabricație: 2015, Funcționalitate: complet funcțional, număr mașină/vehicul: 2460043, Technical characteristics: # Machining Workspace: X 300 mm; Y 500(725) mm; Z 375mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1 axel of rotation table A and 2 axis of rotation B with indexable divider head with direct measuring sistem angular with no of rev. 50minˉ¹ , precision +/- 5" # Max. dimension clamping / part : Ø 575 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 65/75/75 m/min , Position precision Tp : 0.008 mm # Distance between spindles: 300 mm # Spindle speed 1-17500 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 2x32 tools / chip to chip medium 2.5 sec # Tool max.Ø75 mm / long. Max.275 mm / 7.5 kg Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 85 kVA / 125A Dimensions # installation space : aprox. 3.6 x 6 x 3.7 m # weight : aprox 10500 kg Equipment consist of: # CNC control : Siemens 840D SL # Liniar axis measuring device : Heindenhain liniar scales # CHIPS EXTRACTOR Knoll Type 550 K-1 # OIL COOLING SYSTEM # OIL filtering sistem max 80 Bar : Knoll 550 K-1 450_2450 (!!! Can serve 2 machines at once) # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL VAPOR ABSORPTION/RECOVERY SYSTEM : IFS Vario E2000 (2000m3/H) # Antifire : Kraft& Bauer # Part presence P/Y : with low pressure air detectors # Control in process: Marposs T25 Hodpfx Aoxwvr Ieh Hop # Control tool breakage sistem BRK and length check: inductive sensor # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT(spindle) # Documentation: Only books available Machine status : WORKING

Stare: bun (utilizat), An de fabricație: 2015, Funcționalitate: complet funcțional, număr mașină/vehicul: 2460042, Technical characteristics: # Machining Workspace: X 300 mm; Y 500(725) mm; Z 375mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1 axel of rotation table A and 2 axis of rotation B with indexable divider head with direct measuring sistem angular with no of rev. 50minˉ¹ , precision +/- 5" # Max. dimension clamping / part : Ø 575 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 65/75/75 m/min , Position precision Tp : 0.008 mm # Distance between spindles: 300 mm # Spindle speed 1-17500 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 2x32 tools / chip to chip medium 2.5 sec # Tool max.Ø75 mm / long. Max.275 mm / 7.5 kg Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 85 kVA / 125A Dimensions # installation space : aprox. 3.6 x 6 x 3.7 m # weight : aprox 10500 kg Equipment consist of: # CNC control : Siemens 840D SL # Liniar axis measuring device : Heidenhain liniar scales # CHIPS EXTRACTOR Knoll Type 550 K-1 # OIL COOLING SYSTEM # OIL filtering sistem max 80 Bar : Knoll 550 K-1 450_2450 (!!! Can serve 2 machines at once) # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL VAPOR ABSORPTION/RECOVERY SYSTEM : IFS Vario E2000 (2000m3/H) # Antifire : Kraft& Bauer # Part presence P/Y : with low pressure air detectors # Control in process: Marposs T25 # Control tool breakage sistem BRK and length chequer: inductive sensor # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT(spindle) # Documentation: Only books available Machine status : Hedpfx Asxwvlneh Hep WORKING

Stare: foarte bun (second hand), An de fabricație: 2014, Funcționalitate: complet funcțional, producător de controlere: Mitsubishi, Dotări: documentație / manual, transportor de șpan, llalalalalaaaa Hsdpewg Dabjfx Ah Hop

Stare: aproape ca nou (folosit), Sistem de comandă: Fanuc 31i-Model A Cursă de deplasare X / Y / Z: 280 / 330 / 330 mm Dimensiuni masă L x l: 600 x 400 mm Hsdpfx Ahsurbt He Hep Turație ax principal: 15.000 rpm Schimbător de scule: 15 poziții Greutate: aprox. 1.900 kg Dimensiuni L x l x h: aprox. 1.300 x 3.300 x 2.600 metri

Stare: foarte bun (second hand), An de fabricație: 2012, Centru de prelucrare orizontal CNC cu 2 axe, second-hand, an fabricație 12/2012 Disponibil imediat / În stare de funcționare Producător: Schwäbische Werkzeugmaschinen - Schramberg Tip: SW BA 322 / Siemens 840 D sl: bază Windows și tehnologie de acționare servo Power Line An fabricație: 12/2013 Axe: X 300 mm; Y 450 mm; Z 375 mm Ax principal: HSK 63, 1-10.000 rpm, 25 kW la 4.200 rpm, alimentare internă cu lichid de răcire 40 bar Magazie scule: sistem pick-up; capacitate 40 (2x20) poziții scule Hsdpfslxp Ufex Ah Hsp Prindere piesă: sistem port-piese pivotant, axa Q; Două axe de pivotare independente: axe A și U Sistem hidraulic de fixare a piesei, control al poziționării piesei Sistem răcire: 1.200 l; filtru cu bandă de hârtie, filtru tip cartuș, schimbător de căldură, pompă de înaltă presiune Transportor de șpan: transportor cu bandă zgârietoare cu pompă de ridicare, înălțime de evacuare 1.100 mm Ușă automată de încărcare Ciclu automat de spălare, pistol manual de clătire Stare utilaj: curățat, într-o stare bună, alimentat cu medii necesare și funcțional Mașina este verificată de serviciul tehnic SW înainte de preluare și poate fi inspectată oricând, pe bază de programare. Livrare: conform înțelegerii, livrare convenită EXW, Cu drept de revânzare intermediară
