Stare: folosit, An de fabricație: 2017, Funcționalitate: funcționalitate restrânsă, număr mașină/vehicul: MW149, Technical characteristics: Work Area # Maximum turning diameter: 300 mm # Maximum workpiece length: 276 mm # X - axis travel distance: 250 mm / Rapid speed in X: 24 m/min # Z - axis travel distance: 460 mm / Rapid speed in Z: 24 m/min # W -axis travel distance: 520 mm / Rapid speed in Z: 24 m/min Main Spindle # Spindle size : A2-8 # Maximum speed: Left 3000 rpm # Power with 100% ED : Left -15 kW / Right 7.5 kW Bsdpfexxiiiex Alrolk # Max diameter on bench: 520 mm # C axis indexing precision : 0.001 [°] # Bar Capacity: left spindle - 80 mm / right spindle - 53 mm Counter- Spindle: # Spindle speeds : 6000 [rpm] # Max. bar diameter : 53 [mm] # C axis indexing precision : 0.001 [°] # Travel : 520 [mm] Tool Holder with Motorized Tools # Tool Interface: Okuma interface # Number of position : 12 lower -station disc turret, all driven positions # Maximum speed: 4500 rpm, Milling motor power : 4.5 kW Electrical Equipment # Operating voltage: 400Vx3, fusible 151A # Connection power: 22.5 kVA Dimensions # Machine Dimensions (L×W×H): 3200 ×2200× 1900 mm ;Weight : 5500 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation, Parts catcher + Custom made Parts conveying strip # ADDITIONAL EMULSION TANK WITH 10 BAR PRESSURE FOR CUTTING TOOL COOLING # CNC Control: OSP-P300L-R # Chip extraction conveyor # FIRE PROTECTION SYSTEM # TOOL MEASURING SYSTEM (Q SETTER) # Broken tool detection system : Load force auto learning analyzer controlled by OSP-P300L-R # Part detection Counter spindle : Low pressure compressed air gauges. # SPINDLE COOLING SYSTEM, # Documentation : Electronic available / Book available OPTIONAL: Barr feeder : TopAutomazione FU352SX # Bar feeder (L×W×H): 3500 ×800× 1200 mm ;Weight : 1500 Kg Machine status : WORKING only with main spindle - sub spindle needs repaired

Stare: folosit, An de fabricație: 2016, Funcționalitate: funcționalitate restrânsă, număr mașină/vehicul: MW127, Technical characteristics: Work Area # Maximum turning diameter: 300 mm # Maximum workpiece length: 276 mm # X - axis travel distance: 250 mm / Rapid speed in X: 24 m/min # Z - axis travel distance: 460 mm / Rapid speed in Z: 24 m/min # W -axis travel distance: 520 mm / Rapid speed in Z: 24 m/min Main Spindle # Spindle size : A2-8 # Maximum speed: Left 3000 rpm # Power with 100% ED : Left -15 kW / Right 7.5 kW # Max diameter on bench: 520 mm # C axis indexing precision : 0.001 [°] # Bar Capacity: left spindle - 80 mm / right spindle - 53 mm Counter- Spindle: # Spindle speeds : 6000 [rpm] # Max. bar diameter : 53 [mm] # C axis indexing precision : 0.001 [°] # Travel : 520 [mm] Tool Holder with Motorized Tools # Tool Interface: Okuma interface # Number of position : 12 lower -station disc turret, all driven positions # Maximum speed: 4500 rpm, Milling motor power : 4.5 kW Electrical Equipment # Operating voltage: 400Vx3, fusible 151A # Connection power: 22.5 kVA Dimensions # Machine Dimensions (L×W×H): 3200 ×2200× 1900 mm ;Weight : 5500 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation, Parts catcher + Custom made Parts conveying strip # ADDITIONAL EMULSION TANK WITH 10 BAR PRESSURE FOR CUTTING TOOL COOLING # CNC Control: OSP-P300L-R # Chip extraction conveyor # FIRE PROTECTION SYSTEM # TOOL MEASURING SYSTEM (Q SETTER) # Broken tool detection system : Load force auto learning analyzer controlled by OSP-P300L-R # Part detection Counter spindle : Low pressure compressed air gauges. # SPINDLE COOLING SYSTEM, # Documentation : Electronic available / Book available Machine status : WORKING only with main spindle - sub spindle needs to be repaired OPTIONAL: Blodpfsxxihfex Alrek Barr feeder : TopAutomazione model Fu352 SX # Bar feeder (L×W×H): 3500 ×800× 1200 mm ;Weight : 1500 Kg

Stare: necesită reparații (utilizat), An de fabricație: 2016, Funcționalitate: nefuncțional, număr mașină/vehicul: MW144, Technical characteristics: Work Area # Maximum turning diameter: 300 mm # Maximum workpiece length: 276 mm # X - axis travel distance: 250 mm / Rapid speed in X: 24 m/min # Z - axis travel distance: 460 mm / Rapid speed in Z: 24 m/min # W -axis travel distance: 520 mm / Rapid speed in Z: 24 m/min Main Spindle # Spindle size : A2-8 # Maximum speed: Left 3000 rpm # Power with 100% ED : Left -15 kW / Right 7.5 kW # Max diameter on bench: 520 mm # C axis indexing precision : 0.001 [°] # Bar Capacity: left spindle - 80 mm / right spindle - 53 mm Counter- Spindle: # Spindle speeds : 6000 [rpm] # Max. bar diameter : 53 [mm] # C axis indexing precision : 0.001 [°] # Travel : 520 [mm] Tool Holder with Motorized Tools # Tool Interface: Okuma interface # Number of position : 12 lower -station disc turret, all driven positions # Maximum speed: 4500 rpm, Milling motor power : 4.5 kW Electrical Equipment # Operating voltage: 400Vx3, # Connection power: 22.5 kVA Dimensions # Machine Dimensions (L×W×H): 3200 ×2200× 1900 mm ;Weight : 5500 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation, Parts catcher + Custom made Parts conveying strip # CNC Control: OSP-P300L-R # Chip extraction conveyor # FIRE PROTECTION SYSTEM # TOOL MEASURING SYSTEM (Q SETTER) # Broken tool detection system : Load force auto learning analyzer controlled by OSP-P300L-R # Part detection Counter spindle : Low pressure compressed air gauges. # SPINDLE COOLING SYSTEM, # Documentation : Electronic available / Book available OPTIONAL Barr feeder : TOP Automazzione model : FU 352 Bsdjxxidajpfx Alrslk # Bar feeder (L×W×H): 3500 ×800× 1200 mm ;Weight : 1500 Kg Machine status : NOT WORKING # Turret -disassembled to be repaired # Ball screw X axis - to be replaced # Heat exchanger oiling unit - to be replaced # Hydraulic unit - to be replaced # Sub spindle - to be repaired # Position encoder Spindle - to be replaced # Chip conveyor - to be repaired # Kit of guides and accessories for bars clamping # Kit of bearings for pusher head

Stare: necesită reparații (utilizat), An de fabricație: 2015, Funcționalitate: nefuncțional, număr mașină/vehicul: MW137, Technical characteristics: Work Area # Maximum turning diameter: 300 mm # Maximum workpiece length: 276 mm # X - axis travel distance: 250 mm / Rapid speed in X: 24 m/min # Z - axis travel distance: 460 mm / Rapid speed in Z: 24 m/min # W -axis travel distance: 520 mm / Rapid speed in Z: 24 m/min Main Spindle # Spindle size : A2-8 # Maximum speed: Left 3000 rpm # Power with 100% ED : Left -15 kW / Right 7.5 kW # Max diameter on bench: 520 mm # C axis indexing precision : 0.001 [°] # Bar Capacity: left spindle - 80 mm / right spindle - 53 mm Counter- Spindle: # Spindle speeds : 6000 [rpm] # Max. bar diameter : 53 [mm] # C axis indexing precision : 0.001 [°] # Travel : 520 [mm] Tool Holder with Motorized Tools # Tool Interface: Okuma interface # Number of position : 12 lower -station disc turret, all driven positions # Maximum speed: 4500 rpm, Milling motor power : 4.5 kW Electrical Equipment # Operating voltage: 400Vx3, fusible 151A # Connection power: 22.5 kVA Dimensions # Machine Dimensions (L×W×H): 3200 ×2200× 1900 mm ;Weight : 5500 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation, Parts catcher + Custom made Parts conveying strip # ADDITIONAL EMULSION TANK WITH 10BAR PRESSURE FOR CUTTING TOOL COOLING # CNC Control: OSP-P300L-R # Chip extraction conveyor # FIRE PROTECTION SYSTEM # TOOL MEASURING SYSTEM (Q SETTER) # Broken tool detection system : Load force auto learning analyzer controlled by OSP-P300L-R Blodjxxh Udspfx Alrek # Part detection Counter spindle : Low pressure compressed air gauges. # SPINDLE COOLING SYSTEM, # Documentation : Electronic available / Book available OPTIONAL - # Barr feeder : FMB model : Turbo 10-72XT/3200/A # Bar feeder dimensions (L×W×H): 3500 ×800× 1200 mm; Weight: 1500 Kg Machine status : NOT WORKING # Encoder X axis - broken

Stare: folosit, An de fabricație: 2016, Funcționalitate: complet funcțional, număr mașină/vehicul: 46003, Technical characteristics: Bjdsxw Ub Ijpfx Alrelk Work Area # Maximum diameter of the clamping plate: 220 mm # Maximum turning diameter: 170 mm # Maximum machining diameter: 170 mm # Maximum workpiece length: 100 mm # X-axis travel distance: 495 mm / Rapid speed in X: 48 m/min # Z-axis travel distance: 250 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size A5 # Maximum speed: 7000 rpm # Power with 100% OT: 23 kW # Torque with 100% OT :130 Nm Tool Holder with Motorized Tools # turret VDI40, Siemens-drive 0.5.435.220 Fabr. Sauter # Number of position : 12 # Maximum speed: 4000 rpm Electrical Equipment # Operating voltage: 400 V, fusible 80A GL # Connection power: 41 kW Dimensions # Total dimensions: Length=3913 mm,Wide=2160 mm,Height=2955 mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens 840D SL # High Precision: Positioning accuracy in X,Z Heidenhain liniar scales # Main Spindle Weiss: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Control in process probe : Marposs T25 # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyur : Knoll # Coolant ''paper'' filtering unit & cooling : Knoll KF150/950 # Fire extinguisher : Kraft&Bauer # Electrostatic mist filter : IF Vario EC1500 Machine status : WORKING

Stare: folosit, An de fabricație: 1997, Funcționalitate: complet funcțional, număr mașină/vehicul: W301002, Technical characteristics: Work Area # Maximum turning diameter: 270 mm # Maximum machining diameter: 215 mm # Maximum workpiece length: 265 mm # Distance between spindle noses: 1080 mm # X1/X2 - axis travel distance: 195 mm / Rapid speed in X: 12 m/min # Z1/Z2 -axis travel distance: 265/780 mm / Rapid speed in Z: 24 m/min # B -axis travel distance(Right Spindle Travel) : 850 mm / Rapid speed in Z: 24 m/min Spindles # Spindle according to DIN 55026: Size A2-6 # Maximum speed: Left & Right from 50 to 5000 rpm # Power with 100% ED : Left 11 kW / Right11 kW # Main spindle feature : option double command clamping cycle for clamping chuck in 2 steps Bedpsxw Uh Iefx Alrolk # Bar Capacity: left spindle 51 mm / right spindle 51 mm 2 Turrets # Tool Interface: BMT55 # Number of position : 12-station disc turret Electrical Equipment # Operating voltage: 200/220VAC+10%/15%,1 fase, 50/60 Hz # Connection power: 54 kVA (connection 61 VA) Dimensions # Machine Dimensions (L×W×H): 3645 × 1875 × 1970 mm # Weight : 10800 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation and easy loading/unloading. # CNC Control: Fanuc 6i-TT # Chip extraction conveyor # Automation interface available for Gantry loader # Main Spindle with Autoblock Chuck installed 265 TXS # Turret equipped with 2 external tool holders each # Documentation : Electronic not available / Book available Machine status : WORKING

Stare: folosit, An de fabricație: 2016, Funcționalitate: complet funcțional, număr mașină/vehicul: 46001, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 220 mm # Maximum turning diameter: 170 mm # Maximum machining diameter: 170 mm # Maximum workpiece length: 100 mm # X-axis travel distance: 495 mm / Rapid speed in X: 48 m/min # Z-axis travel distance: 250 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size A5 # Maximum speed: 7000 rpm # Power with 100% OT: 23 kW # Torque with 100% OT :130 Nm Tool Holder with Motorized Tools # turret VDI40, Siemens-drive 0.5.435.220 Fabr. Sauter # Number of position : 12 # Maximum speed: 4000 rpm Electrical Equipment # Operating voltage: 400 V, fusible 80A GL # Connection power: 41 kW Dimensions # Total dimensions: Length=3913 mm,Wide=2160 mm,Height=2955 mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens 840D SL # High Precision: Positioning accuracy in X,Z Heidenhain liniar scales # Main Spindle Weiss: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Control in process probe : Marposs T25 # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor : Knoll # Coolant ''paper'' filtering unit & cooling : Knoll KF150/950 # Fire extinguisher : Kraft&Bauer # Electrostatic mist filter : IF Vario EC1500 Blsdpfx Aexw Ufyelrek Machine status : WORKING

Stare: necesită reparații (utilizat), An de fabricație: 2016, Funcționalitate: nefuncțional, număr mașină/vehicul: 107965, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 160 mm # Maximum turning diameter: 160 mm # Maximum machining diameter: 100 mm # Maximum workpiece length: 150 mm # X-axis travel distance: 700 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 375 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size A5 # Maximum speed: 6000 rpm # Power with 100 / 40% duty cycle: 18.1 / 13.9 kW # Torque with 100 / 40% duty cycle: 77 / 59 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - BMT65 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V ,80 A # Connection power: 27 kVA Dimensions # Total dimensions: Length=4350 with chip extractor,Wide=1600 mm,Height=2500 mm # Weight : 5500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc FS 32i B. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Control in process: Measuring probe Marposs T25 # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring with sister tool management # Chip conveyor & coolant filtration unit Knoll with ''paper filter'' with 40 Bar pumps ( capable to filter 2 Machines) # Fully enclosed work area Light in working area # Documentation : Electronic available & Book not complete Machine status : NOT WORKING # Life tool Motor # Loading door Safety Euchner # Turret Motor # Driver turret Motor # Oiling pump # Hydraulic block electrovalvula x4 units Bodpexw Sviefx Alrjlk # Oiling pressure # Rotary joint # Loading door hydraulic cylinder # Spindle clamp/unclamp sensor

Stare: folosit, An de fabricație: 2015, Funcționalitate: complet funcțional, număr mașină/vehicul: 106679, Technical characteristics: Work Area # Chuck diameter: 260 mm # Weight max. : 150 Kg # Swing diameter: 280 mm # Workpiece dia. / height max.: 200/200 mm # X stroke(working stroke): 760 mm / Rapid speed in X: 60 m/min / feed force 6.9 kN # Y stroke: +/-30 mm / Rapid speed in X: 15 m/min / feed force 7.5 kN # Z stroke: 415 mm / Rapid speed in Z: 30 m/min / feed force 18.7 kN # Loading time : 5÷6 sec # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 25 / 18 kW # Torque with 100 / 40% duty cycle: 280 / 200 Nm Bledpfexw Smbex Alrsk Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - BMT65 # Number of position : 12 # Maximum tool length including holder: 200 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V ,100 A # Connection power: 36 kVA Dimensions # Total dimensions: Length=5300 with chip extractor,Wide=2300 mm,Height=3650 mm # Weight : 9000 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc FS 32i B. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Control in process: Measuring probe Marposs T25 # Automated Loading/Unloading: Emag O-Type Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring with sister tool management # Chip conveyor&coolant filtration unit Micronfilter with ''paper filter'' with 40 Bar pumps(capable to filter 2 Machines) # Fully enclosed work area Light in working area # Documentation : Electronic available & Book not complete Machine status : WORKING

Stare: necesită reparații (utilizat), An de fabricație: 2016, Funcționalitate: nefuncțional, număr mașină/vehicul: 107964, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 160 mm # Maximum turning diameter: 160 mm # Maximum machining diameter: 100 mm # Maximum workpiece length: 150 mm # X-axis travel distance: 700 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 375 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size A5 # Maximum speed: 6000 rpm # Power with 100 / 40% duty cycle: 18.1 / 13.9 kW # Torque with 100 / 40% duty cycle: 77 / 59 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - BMT65 # Number of position : 12 # Maximum tool length including holder: 190 mm Bodpfx Asxw Srkjlrelk # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V ,80 A # Connection power: 27 kVA Dimensions # Total dimensions: Length=4350 with chip extractor,Wide=1600 mm,Height=2500 mm # Weight : 5500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc FS 32i B. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Control in process: Measuring probe Marposs T25 # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring with sister tool management # Chip conveyor # Fully enclosed work area Light in working area # Documentation : Electronic available & Book not complete Machine status : NOT WORKING # Cooling Pump x2 units # Life Tool Motor # Oiling Pump # Operator panel - touch screen need to be changed # Hydraulic block valves x 3 units # Hydraulic cylinder loading door # Rotary Joint # Oiling Pressure switch # Safety door Euchner

Stare: folosit, An de fabricație: 2014, Funcționalitate: funcționalitate restrânsă, număr mașină/vehicul: 179057784, Technical characteristics: Work Area # Chuck diameter: 600 mm # Workpiece dia. / height max.: 450 / 400 mm # Distance spindle nose vs. origin tailstock : 639 mm # X1/X2 stroke(working stroke): 335/289 mm / Rapid speed in X: 30 m/min # Z1/Z2 stroke: 560/494 mm / Rapid speed in Z: 30 m/min # Standard closed with automatic door opening - manual or automatic loading option Main Spindle # Spindle according to DIN 55026: Size A6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 23 / 18 kW # Torque with 100 / 40% duty cycle: 146 / 115 Nm Tailstock # Interface: MK4 # Clamping force: 850 daN # Clamping stroke: 200 mm Turret config X1/Z1 : Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 8 - VDI40 # Max Tool Length : 130 mm # Number of position : 1 x 8 # Maximum speed: 4500 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Turret config X2/Z2 : Tool Holder with Motorized Tools # X-HOT unit for poligonal shapes machining max. eccentricity (Stroke): 8 mm # X-HOT Clamping system tool holder : HSK 32S Bjdpfx Alexw R Rfjrjlk Electrical Equipment # Operating voltage: 400 V ,100 A # Connection power: 37 kVA Dimensions # Total dimensions: Length=3000(6477 with chip extractor), Wide=3000 mm,Height=3650 mm # Weight : 11000 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation ,manual or automatic loading/unloading. # Control: Siemens 840D controlling NC1 and NC2 # High Precision: Positioning accuracy in X,Z axes is ±0.002 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring # Chip conveyor Coolant : Knoll # Coolant filtration unit max 40Bar : Knoll FKA/1400 # Part presence detection system : with low air pressure detector # AUTOMATION INFRASTRUCTURE FOR # ROBOT INSTALLED # Fully enclosed work area Light in working area # Documentation : Electronic available & Book available Machine status : WORKING only X1/Z1 - X2/Z2 working, but no XHOT available

Stare: necesită reparații (utilizat), An de fabricație: 2016, Funcționalitate: nefuncțional, număr mașină/vehicul: 107786, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 160 mm # Maximum turning diameter: 160 mm # Maximum machining diameter: 100 mm # Maximum workpiece length: 150 mm # X-axis travel distance: 700 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 375 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size A5 # Maximum speed: 6000 rpm # Power with 100 / 40% duty cycle: 18.1 / 13.9 kW # Torque with 100 / 40% duty cycle: 77 / 59 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - BMT65 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V ,80 A # Connection power: 27 kVA Dimensions # Total dimensions: Length=4350 with chip extractor,Wide=1600 mm,Height=2500 mm # Weight : 5500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc FS 32i B. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Control in process: Measuring probe Marposs T25 # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring with sister tool management # Chip conveyor # Fully enclosed work area Light in working area # Documentation : Electronic available & Book not complete Machine status : NOT WORKING # Operator panel - touch screen need to be changed # Hydraulic cylinder loading door broken # Emulsion Pump # Hydraulic pump Bledpfx Alsxw Slkorsk # Spindle clamp unclamp sensor # Hydraulic pressure accumulator # Turret motor

Stare: bun (utilizat), An de fabricație: 2015, Funcționalitate: complet funcțional, număr mașină/vehicul: 15KX239200001, Technical characteristics: Work Area # Maximum turning diameter: 210 mm # Maximum machining diameter: 200 mm # Maximum workpiece length: 220 mm # X1/X2 - axis travel distance: 220 mm / Rapid speed in X: 24 m/min # Z1/Z2 -axis travel distance: 220/770 mm / Rapid speed in Z: 36 m/min # Y1/Y2-Axis travel distance: +/-40mm / Rapid speed in Z: 12 m/min Automatization: # Axis Stroke: X - 210 mm ; Y - 680 mm ; Z - Left 2080 mm / Right 3360 mm ; α 270˚ # Max speeds m/min : X - 35 ; Y - 120 mm ; Z - 160 mm ; α 270˚/1.5 sec # Specification of load / un load grippers (air pressure powered) : outer diameter - Ø170; jaw stroke 30mm ; gripping force : outside 128kgf / inside 138kgf Main Spindle # Spindle size : A8 # Maximum speed: Left 5000 rpm / Right 5000rpm # Power with 100% ED : Left -15 kW / Right 7.5 kW # Bar Capacity: left spindle - 65 mm / right spindle - no Tool Holder with Motorized Tools # Tool Interface: BMT55 # Number of position : 15 upper / 12 lower -station disc turret, all driven positions # Maximum speed: 4500 rpm, Milling motor power : 4.5 kW Electrical Equipment # Operating voltage: 200Vx3, fusible 151A Bsdpexwuhusfx Alrelk # Connection power: 55 kVA Dimensions # Machine Dimensions (L×W×H): 3200 ×2200× 3500 mm # Weight : 10500 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation, loading/unloading by gantry from conveyors # Automatization consist of : Gantry robot + 2 loading unloading conveyors # CNC Control: Fanuc FS31i Model A Series # Chip extraction conveyor # Coolant filtration 40 bar max : Filber S.L. FTH5/10 200l/min # Control in process : Marposs T25 # Broken tool detection sistem : Peek tool menu Murata/Fanuc feature activated # Part detection throw spindle : Low pressure compressed air gauges. # Barr feeder interface max Ø65 mm # Documentation : Electronic available / Book available Machine status : WORKING

Stare: bun (utilizat), An de fabricație: 2007, Funcționalitate: complet funcțional, număr mașină/vehicul: 41015, Technical characteristics: Work Area # Chuck diameter: 210 mm # Workpiece dia. / height max.: 200/200 mm # X1/X2 stroke(working stroke): 160 mm / Rapid speed in X: 24 m/min Bledpfx Aoxwmcwjlrsk # Z1/Z2 stroke: 250 mm / Rapid speed in Z: 30 m/min Main Spindle # Spindle configuration: 4 spindles (dual machining + dual loading) / Size A2-6 # Distance between spindles: 282.5 mm # Maximum speed: 4500 rpm # Power : 18.5 kW Tool Holder with Motorized Tools # Turret configuration: 2 turrets # Number of position : 2 x 10 # Maximum speed: 4000 rpm / Power 3.7 Kw Electrical Equipment # Operating voltage: 400 - 480 V ,120 A # Connection power: 66 kVA Dimensions # Total dimensions: Length =3336 with chip extractor,Wide=2400 mm, Height=1760mm # Weight : 7000 Kg Main Features and Capabilities: # Control: FANUC 0i-TF Plus # Main Spindle: High power and wide speed range. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip conveyor # Fully enclosed work area # CHIPS EXTRACTOR, # COOLING SYSTEM ELECTRICAL PANEL, # LUBRICATION SYSTEM, # HYDRAULIC OIL COOLING SYSTEM. # AUTOMATIOZATION INFRASTRUCTURE FOR ROBOT INSTALLED # Documentation : Electronic available & Book available Machine status : WORKING

Stare: necesită reparații (utilizat), An de fabricație: 2006, Funcționalitate: nefuncțional, număr mașină/vehicul: 00592, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 200 mm # Maximum machining diameter: 130 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 400 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 7500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Bledpjxwlbxofx Alrsk Electrical Equipment # Operating voltage: 3x 400 - 480 V , 50A # Connection power: 31 kW Dimensions # Total dimensions: Length =2680mm(3820 with chip extractor),Wide=2040 mm, Height =2400mm # Weight : 5500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE FanucSeries 18i TB. # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor # Documentation : Electronic not available / Book available Machine status : NOT WORKING # Motor from Life tool broken # Reductor from life tool broken

Stare: necesită reparații (utilizat), An de fabricație: 2011, Funcționalitate: nefuncțional, număr mașină/vehicul: 66101, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 250 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 200 mm # X-axis travel distance: 626 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 250mm / Rapid speed in Z: 30 m/min # Y-axis travel distance: +100/-90 mm / Rapid speed in Y: 30 m/min # Standard closed work piece automation Pick-up station from individual nests conveyour highway Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 5500 rpm # Power with 100% ED : 38 kW # Torque with 100 % ED: 300 Nm Tool Holder with Motorized Tools # Tool Interface: VDI40 DIN 5480 # Number of position : 12-station disc turret, all driven positions # Maximum speed: 6000 rpm, Torque Capacity: 70–100 Nm per driven station Blsdpfxoxwk S Ae Alrok Electrical Equipment # Operating voltage: 2x400, fusible 160A GL # Connection power: 90 kW Dimensions # Total dimensions: Lenght=3390mm,Wide=2850 mm,Height=2400mm # Weight : 16000 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens 840D SL # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools by Sauter turret: The possibility of using live tools extends the machining range to include drilling and milling. # Cooling & ''paper'' filtering unit : DGS System GMBH 950L # Chip extraction conveyor : DGS System GMBH # Hydraulic unit : Rexroth Q=13 l/min , pmax=65 bar # Mist extraction units : IFS model IFM1000 # Documentation availability : Yes. Machine status : NOT WORKING # Pick-up pneumatic cylinder # Turret indexation motor # Closing door pneumatic piston # Door safety Euchner switch # Liniar scale Z axis # Siemens Power source

Stare: bun (utilizat), An de fabricație: 2008, Funcționalitate: complet funcțional, număr mașină/vehicul: 101868, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 260 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 570 mm / Rapid speed in X: 60 m/min Bodpfx Aljxwk U Djrelk # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Y-axis travel distance: 40 mm / Rapid speed in Y: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V # Connection power: 42 kW Dimensions # Total dimensions: Lenght=2680mm(3820 with chip extractor),Wide=2040 mm,Height=2400mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE FanucSeries 18i TB. # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor Machine status : WORKING

Stare: necesită reparații (utilizat), An de fabricație: 2009, Funcționalitate: nefuncțional, număr mașină/vehicul: 101851, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 260 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 570 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Y-axis travel distance: 40 mm / Rapid speed in Y: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V # Connection power: 42 kW Dimensions # Total dimensions: Length =2680mm(3820 with chip extractor),Wide=2040 mm, Height =2400mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE FanucSeries 18i TB. # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. Blodoxvy Azopfx Alrsk # Chip extraction conveyor Machine status : NOT WORKING # Motor from Lifetool # Optical scale X axis broken + connection cable # Belt Z axis # Oiling Presostat # Hidraulic main pressure valve # Door safety Euchner

Stare: necesită reparații (utilizat), An de fabricație: 2011, Funcționalitate: nefuncțional, număr mașină/vehicul: 68178, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 250 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 200 mm # X-axis travel distance: 626 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 250mm / Rapid speed in Z: 30 m/min # Standard closed work piece automation by Gantry loader from individual nests conveyor highway Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 5500 rpm # Power with 100% ED : 38 kW # Torque with 100 % ED: 300 Nm Tool Holder with Motorized Tools # Tool Interface: VDI40 DIN 5480 # Number of position : 12-station disc turret, all driven positions # Maximum speed: 6000 rpm, Torque Capacity: 70–100 Nm per driven station Electrical Equipment # Operating voltage: 2x400, fusible 160A GL # Connection power: 90 kW Dimensions # Total dimensions: Length =3390mm,Wide=2850 mm, Height=2400mm # Weight : 16000 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens 840D SL # High Precision: Positioning accuracy in X,Z axes by Heidenhain liniar scales # Main Spindle Weiss: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools by Sauter turret: The possibility of using live tools extends the machining range to include drilling and milling. # Cooling & ''paper'' filtering unit : DGS System GMBH 950L # Chip extraction conveyor : DGS System GMBH Blodpfxexwk Iws Alrok # Hydraulic unit : Rexroth Q=13 l/min , pmax=65 bar # Mist extraction units : IFS model IFM1000 # Documentation availability : Yes. Machine status : NOT WORKING # Loading/unloading slide ways doors defective # Liniar scale X axis 2 units # Turret position sensor (furT30) # Sensor Clamp Unclamp Spindle # Electro valve emulsion - 4 units

Stare: necesită reparații (utilizat), An de fabricație: 2008, Funcționalitate: nefuncțional, număr mașină/vehicul: 101850, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 260 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 570 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Y-axis travel distance: 40 mm / Rapid speed in Y: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V # Connection power: 42 kW Dimensions # Total dimensions: Length =2680mm(3820 with chip extractor),Wide=2040 mm, Height =2400mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc Series 18i TB. # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor Machine status : Bsdpfx Asxvyh Rolrelk NOT WORKING # Motor from Life tool # Optical scale X axis # Optical scale Z axis # Belt Z axis # Driver unit Z-X axis # Cable Optical scale axis X,Z # Emulsion Pump

Stare: necesită reparații (utilizat), An de fabricație: 2012, Funcționalitate: nefuncțional, număr mașină/vehicul: 103563, Technical characteristics: Work Area: # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 260 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 570 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Y-axis travel distance: 40 mm / Rapid speed in Y: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle: # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V # Connection power: 42 kW Dimensions # Total dimensions: Length =2680mm(3820 with chip extractor),Wide=2040 mm, Height =2400mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens Sinumerik 840D-sl. # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales Bsdpfx Asxvyk Eelrjlk # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor Machine status : NOT WORKING # Motor from Life tool - dismantled from machine # Spindle broken - dismantle from machine # Turret dismantled ( leakage if cooling coolant throw refrigeration circuit of turret )

Stare: folosit, An de fabricație: 2008, Funcționalitate: complet funcțional, număr mașină/vehicul: M250.81009, Technical characteristics: # Main Drive: * Connected Load: 400 V/50 Hz / 43 kW * Drive Power of Main Spindle (100% ED / 40% ED): 18 kW / 28 kW * Main Spindle Torque: 300 Nm * Speed Range: 0-4500 rpm * Spindle Head: DIN 55026-A6 Bledpfxoxvx T Ss Alrsk # Working Area:Rapid Traverse X-axis: 60 m/min * Rapid Traverse Z-axis: 30 m/min * Feed Force X-axis: 10 kN * Feed Force Z-axis: 10 kN # Control: * Siemens SINUMERIK 840Dsl * 15-inch TFT Monitor. # Working Accuracy: * Axes (X-axis / Z-axis): ±0.001 mm * Spindle (C-axis): ±0.01° # Tool Carrier: * EMAG Flange Turret Generation C361 - Capto C5. *. * Holder Shank Diameter: TN340009 * Max. Tool Dimensions: Workpiece-dependent. * Tool Change Times (Turret / Live Tool): 0.03 min / 0.04 min. * Max. Speed of Live Tool: 6000 rpm. * Max. Torque of Live Tool (100% ED / 10% ED): 15 Nm/3.5 kW / 40 Nm/8.5 kW. # Coolant System: * Standard Delivery Pressure / Max. Delivery Pressure: 7 bar * Pressure Range of Internal Coolant Supply: 7 bar (not adjustable) * Coolant Tank Capacity: 360 liters # Part Catcher: * No part catcher available. Parts are fed to and removed from the machine via automation. Ambient Conditions (Room temperature / Air humidity): up to approx. 30°C / max. 50% * Noise Level (Sound Pressure Level / Sound Power Level): 78 dB(A) # General: * Machine Dimensions (L x W x H): 3900 mm x 1500 mm x 3200 mm * Machine Weight: approx. 7000 kg * Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens SINUMERIK 840Dsl with integrated PLC S7-300 and a 15-inch TFT monitor. # High Precision: Positioning accuracy in X and Z axes is ±0.001 mm. # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip conveyour # Chuck installed : EMB3 Expanding mandril Autoblock # Capto C5 tool holders installed on turret ( External/internal machining 2 units & 2 lifetools ) # Tool load monitor Artis capability available

Stare: revizuit în atelier (folosit), An de fabricație: 2001, Funcționalitate: complet funcțional, diametru de strunjire deasupra saniei transversale: 270 mm, alezor axului principal: 77 mm, diametru de strunjire: 505 mm, diametru de strunjire peste patul saniei: 505 mm, înălțime centru: 250 mm, lățime la centru: 1.500 mm, lungime de strunjire: 1.500 mm, trăsătură de pană: 180 mm, diametru quill: 80 mm, cursa axului: 180 mm, lungime totală: 3.095 mm, lățime totală: 1.100 mm, înălțime totală: 1.525 mm, turația arborelui principal (max.): 2.000 rot/min, viteza axului (min.): 13 rot/min, diametru de oscilație peste sania transversală: 270 mm, diametrul filetului metric (min.): 1 mm, diametrul filetului metric (max.): 40 mm, pași de filet metric: 29, lățimea patului: 340 mm, Diametru de strunjire în deschidere: 700 mm, viteză de rotație (max.): 2.000 rot/min, viteză de rotație (min.): 13 rot/min, diametru de oscilație deasupra tălpii transversale: 505 mm, greutate totală: 2.400 kg, avans rapid axa X: 1 m/min, avans rapid pe axa Z: 3 m/min, suport manșon: MK 5, diametrul mandrinei cu trei bacuri: 250 mm, Trens SN500 Classic – Strung universal recondiționat, 2001 Oferim acest strung universal Trens SN500 Classic, complet recondiționat, fabricat în 2001, revizuit în întregime de către tehnicieni ai fabricii producătoare, readus într-o stare apropiată de cea nouă. Detalii tehnice: Producător: Trens Model: SN500 Classic Anul fabricației: 2001 Tipul mașinii: strung universal manual Tipul comenzii: manuală Diametrul maxim de prelucrare deasupra patului: 505 mm Diametrul maxim de prelucrare deasupra saniei transversale: 270 mm Diametrul maxim de prelucrare în golul patului: 700 mm Distanța dintre centre: 1500 mm Înălțimea centrelor: 250 mm Conul arborelui principal: BAJONET DIN (ISO702-III) B8 Diametrul interior al arborelui principal: 77 mm Bjdpfx Aljzndb Esrslk Intervalul de turații al arborelui principal: 12,5–2000 min⁻¹ (18 trepte) Puterea motorului principal: 7,5 kW Cuplul maxim: 1450 Nm Suportul standard pentru scule: suport cu 4 poziții, dimensiunea maximă a sculei 32×25 mm Cilindrul contrabacului: MORSE 5, diametru 80 mm, cursă 180 mm Filete metrice: 29 de pasuri, 0,5–40 mm Filete Whitworth: 38 de pasuri, 1–80 TPI Dimensiunile mașinii (Î×L×A): 1525 mm × 1100 mm x 3095 mm Greutate: aprox. 2400 kg (fără accesorii) Accesorii incluse: Mandrină cu 3 bacuri TOS Svitavy IUS 250/3-2-M1, ø 250 mm, prindere B8 Mandrină cu 4 bacuri Bison 4335-315-8, ø 315 mm, prindere B8 Suport fix, ø 10–115 mm, cu 3 puncte de contact prin frecare (puncte de contact cu rulmenți disponibile ca opțiune contra cost) Suport mobil, ø 10–115 mm, cu 2 puncte de contact prin frecare (puncte de contact cu rulmenți disponibile ca opțiune contra cost) Suport fix mare I, ø 110–250 mm, cu 3 puncte de contact prin frecare (puncte de contact cu rulmenți disponibile ca opțiune contra cost) Scopul recondiționării: Toate ghidajele șlefuite și finisate manual Arborele principal șlefuit și recondiționat Cilindrul contrabacului șlefuit Toate rulmenții noi, inclusiv rulmenții arborelui principal Angrenaje noi Vopsire nouă Plăcuțe noi (tabele de turații, avansuri și filete) Mașina se află într-o stare mecanică excelentă și este gata de utilizare imediată. Poate fi inspectată. Protocol geometric disponibil. Manual electronic al mașinii pe USB. Pentru întrebări sau detalii suplimentare, nu ezitați să ne contactați prin mesaj sau telefon.

Stare: foarte bun (second hand), An de fabricație: 2007, Vă rugăm să citiți cu atenție specificațiile tehnice. Dacă această mașină reprezintă o opțiune viabilă pentru o investiție, vă rugăm să ne furnizați informațiile complete de identificare, inclusiv un număr de telefon și o adresă de e-mail corecte, pentru a vă putea oferi o ofertă. !!! ACEASTĂ MAȘINĂ ESTE ÎN PREZENT ÎN CURS DE REPARAȚIE !!! IMAGINILE NU CORESPUND MAȘINII OFERTATE, CI PREZINTĂ O MAȘINĂ REPARATĂ RECENT, CU O CURSĂ MAI MICĂ !!! Oferim aici o strung de precizie deosebit de bună. Această mașină este, probabil, cea mai bună strung germană din această clasă, care a fost construită. Strung de precizie BOHEHRINGER, model DUE 560 An de fabricație: 2007, inclusiv certificare CE + sistem de lubrifiere centrală Înălțimea centrului: 280 mm Bledpow Rdthefx Alrok Diametrul maxim al piesei de prelucrat deasupra bazei: 560 mm Diametrul maxim al piesei de prelucrat deasupra saniei transversale: 315 mm Distanța dintre centre: aprox. 2.000 mm Diametrul barei: 62 mm Capul de strunjire: DIN 55027, mărimea 6 Diametrul fusului: 100 mm Puterea motorului: 11 kW Cuplu maxim: 2.000 Nm 24 de viteze de rotație: 11,2 – 2.240 rpm 60 de avansuri pentru sania transversală: 0,03 – 28 mm/rot. 60 de avansuri pentru sania longitudinală: 0,06 – 56 mm/rot. Cursa pinolei saniei port-scule: 190 mm Conul saniei port-scule: MK 5 Spațiul necesar: L x l, aprox. 4.300 x 1.525 mm Greutate: aprox. 4.600 kg Accesorii: - Afișaj digital cu 3 axe HEIDENHAIN - Sistem de lubrifiere centrală - Protecție pentru mandrină cu blocare electrică - Sistem de răcire - Panou de protecție pentru așchii - Mandrină cu 3 bacuri T 250 mm, inclusiv diverse bacuri de fixare - Husă pentru banda de transport pentru suportul spirei de ghidare, fixată pe bază - Lampă de lucru - Multifix C + 3 suporturi interschimbabile - Manual de operare - Schemă electrică - Avans rapid pentru suportul longitudinal și transversal Stare: Mașina este într-o stare tehnică și optică foarte bună. Jocul invers al saniei transversale: aprox. 0,2 mm, iar al saniei superioare: aprox. 0,15 mm Bătăile conului fusului: aprox. 0,006 mm Geometria bazei mașinii: deviație de aprox. 0,01 mm pe o lungime a bazei de aprox. 750 mm (măsurată pe ghidajul cu suprafață plană, cu ajutorul unui comparator, în direcția mandrinei) Au fost înlocuite următoarele piese: - Schimb de ulei - Furtunuri noi pentru sistemul de lubrifiere centrală - Ștergătoare noi - Înlocuirea diverselor piese de uzură - Revopsirea completă a mașinii și verificarea funcțională tehnică Disponibilă începând cu sfârșitul lunii septembrie 2026. Prețul este net, franco încărcare în depozit. La cerere, se poate oferi livrare cu camionul nostru.

An de fabricație: 2014, ore de funcționare: 8.674 h, stare: gata de utilizare (folosit), - STRUNG CNC CU 2 AXE - FOLOSIT DISTANȚA ÎNTRE VÂRFURI: 1750 mm DIAMETRU MAXIM DE ROTIRE: 820 mm DIAMETRU MAXIM DE STRUNJIRE: 730 mm CAPACITATE BARĂ: 115 mm AX PRINCIPAL: 1500 rpm; 30 - 37 kW; ASA 2-11 ; 510 mm CURSĂ AXĂ X: 365+25 mm CURSĂ AXĂ Z: 1650 mm CUTIE DE VITEZE: 4 TREPTE AVANS RAPID X-Z: 15 - 12 m/min CAP TOURELĂ: 10 POZIȚII UNITATE DE CONTROL: FANUC 0i-TD GREUTATE: 12800 Kg DIMENSIUNI TOTALE: 6200 x 2500 x 2500 mm ACCESORII: CONTRAPUNCT ROTATIV; TRANSPORTOR AȘCHII; PORT ETHERNET; PORT SERIAL PCMCIA; Blodpfeq H Tr Tjx Alrsk PORT SERIAL RS 232; PORT USB
